🇬🇧 Kv2 Audio SDD3 ☎️Call for Quote


Description

The SDD3 is a true technology statement by KV2 Audio. It utilises our ground breaking 20MHz PDM digital conversion process developed for time alignment applications in our speaker range. The SDD3 incorporates high quality line driver outputs to allow users to deliver pristine audio signal to delay speakers or under balcony fills over 100m from the source. The ultimate choice for the distribution of time corrected audio signal, the SDD3 has two super digital channels that will deliver up to 400 milliseconds of delay. Each of these channels has an adjustable HPF and is easily programmed through the front panel menu where all settings can be stored and recalled for varying situations. It also has a third channel with up to 10 milliseconds of delay for configuring cardoid subwoofer setups. Ideal for large stadiums, theatres, concert halls or any application where time correction is required to achieve optimum audio quality.

System Acoustic Performance

-1dB Response 2Hz to 40kHz
-10dB Response 2Hz to 100kHz
Sampling Frequency 20MHz, PDM
Dynamic Range >105dB
Channel Crosstalk 90dB
Signal to Noise Ratio 105dB
Total Harmonic Distortion 0.005%

Signal Input

Input Channels 2 Full range + 1 Subwoofer
Input Impedance 20kΩ (balanced)
Max. Input voltage +14dBu
Line input XLR

Signal Output

Signal Output Channels 2 Full range + 2 Subwoofer
Output Impedance 50Ω
Through Signal Output XLR
Delay Signal Output XLR

Features

Input Level Control -10 / +10dB
Subwoofer Level Control -10 / +10dB
System setup Normal / Cardioid mode
Delay Range 0.012ms ÷ 393.216ms, step 0.003ms
Full Range Mode 2 channels
Phase 0° / 180°
High Pass Filter OFF to 260Hz
Indicators OLED Display
Memory 30

Power Requirements

Power Connector IEC 320
Operating Voltage 115V / 230V
Operating Voltage Range 90 to130V@60Hz | 180 to 260V@50Hz

Physical Dimensions

Height 44 mm (1.75")
Width 482.6 mm (19.0")
Depth 203 mm (7.9")
Weight 3.6 kg (7.94lbs)
